PY Spring Cone Crusher

Usage and Application
Spring cone crusher is mainly used for medium and fine crushing of medium degree hardness materials and above, such as basalt, granite, river stone, iron ore, etc. It is widely used in metallurgy, building material, mining and other fields.

Features
1. Reliable structure, steady performance;
2. Long life for wear parts, low working cost;
3. Dry oil seal is adopted to isolate dust from lubricating oil and extend the service life of the equipment;
4. Oil station continuously supplies oil for lubrication, which to reduce downtime for maintenance.

The motor drives eccentric bushing via spring coupling, transmission shaft and a couple of cone gear wheel, the main shaft of eccentric bushing would drive mantle to do pendulum movement, so as to mantle would be close to concave and far from concave. Materials would be continuously extruded, bended and impacted, crushed materials would be discharged from bottom discharge mouth under the action of gravity.

Model	Max. Feeding Size (mm)	Adjustable Range of Outlet (mm)	Capacity (t/h)	Motor Power (kW)	Weight (t)	Overall Dimension (mm)
PYB600	65	12-25	20-40	30	5	2234×1370×1675
PYD600	35	3-13	12-23	30	5.5	2234×1370×1675
PYB900	115	15-50	50-90	55	11.2	2692×1640×2350
PYZ900	60	5-20	20-65	55	11.2	2692×1640×2350
PYD900	45	3-13	15-50	55	11.3	2692×1640×2350
PYB1200	145	20-50	110-168	110	24.7	2790×1878×2844
PYZ1200	100	8-25	42-135	110	25	2790×1878×2844
PYD1200	50	3-15	18-105	110	25.6	2790×1878×2844
PYB1750	215	25-60	280-480	160	50.3	3910×2894×3809
PYZ1750	185	10-30	115-320	160	50.3	3910×2894×3809
PYD1750	85	5-15	75-230	160	50.4	3910×2894×3809
PYB2200	300	30-60	490-800	260/280	80	4622×3302×4470
PYZ2200	230	10-30	200-580	260/280	80	4622×3302×4470
PYD2200	100	5-15	120-340	260/280	81.4	4622×3302×4470

Note: 1. Any change of technical data will not inform additionally.
