Mobile Crushing Plant

Usage and Application
YCZ series mobile crushing plant consists of crushing and screening, reasonably combined with tyred trailer. It could move flexibly based on change of working site.

Features
1. Strong adaptability, flexible and able to enter working mode quickly.
2. Standard tyred axle and traction steering axle are adopted, which is more conducive to highway transportation transfer.
3. Compact structure design saves space and reduces the floor area of production site.
4. The equipment process is reasonable and smooth, with high type matching degree and high operation efficiency.
5. The management of equipment foundation is simple and fast, greatly reduces the civil construction period.
6. Easy and fast installation, safe and efficient.
7. According to the construction needs, it can be quickly transferred and re-installed.
8. Complete supporting facilities, once electricity is connected, it could work immediately.
9. The configuration combination is flexible, can not only be treated as a single machine for independent operation, but also be coarse crushing, medium crushing, fine crushing, screening and other combinations into a multi-stage crushing and screening system.

The mobile crushing plant is not limited by the crushing place, and reduces high material transportation cost. It can crush materials on site or nearly. It is widely used in the industry of mining, metallurgy, building materials, traffic, water conservancy and so on.

Coarse Crushing Mobile Plant

Model	Corollary Equipment		Feeding Size （mm）	Capacity (t/h)	Main Equipment Power (kw)
	Crushing Equipment	Feeding Equipment
YCZ-E80	PE500×750	GZD850×3000	＜425	40-120	62.5
YCZ-E120	PE600×900	GZD960×3800	＜500	60-160	86
YCZ-E180	PE750×1060	GZD1100×4200	＜630	110-270	125
YCZ-E260	PE900×1200	GZD1300×4900	＜750	150-380	154
YCZ-EW60	PEW400×600	GZD850×3000	＜350	15-75	44.5
YCZ-EW220	PEW760×1100	GZD1100×4200	＜640	150-330	125
YCZ-EW280	PEW860×1100	GZD1300×4900	＜720	200-450	154
YCZ-EW420	PEW1100×1200	GZD1500×6000	＜930	300-650	215

Medium Crushing and Screening Mobile Plant

Model	Corollary Equipment		Feeding Size （mm）	Capacity (t/h)	Main Equipment Power (kw)
	Crushing Equipment	Screening Equipment
YCZ-F70	PF1010	3YZS1548	＜300	50-90	90
YCZ-F120	PF1214	3YZS1860	＜300	90-180	154
YCZ-F175	PF1315	3YZS2160	＜350	120-250	190
YCZ-FW125	PFW1214Ⅲ	3YZS1860	＜250	90-190	154
YCZ-FW200	PFW1315Ⅲ	3YZS2160	＜300	150-270	190
YCZ-FW260	PFW1318Ⅲ	3YZS2160	＜300	220-320	230
YCZ-Y-B70	PYB900	3YZS1548	＜115	50-90	70
YCZ-Y-B120	PYB1200	3YZS1860	＜145	110-170	132
YCZ-CS-B90	CZS36B	3YZS1848	＜152	45-165	93.5
YCZ-CS-B180	CZS51B	3YZS2160	＜220	109-360	190
YCZ-HP-C160	HPC200C1	3YZS1860	＜185	150-250	182
YCZ-HP-C240	HPC300C2	3YZS2160	＜230	220-440	280
YCZ-HS-C130	HSC100C2	3YZS1860	＜240	85-170	112
YCZ-HS-C210	HSC160C2	3YZS2160	＜360	120-345	190

Fine Crushing and Screening Mobile Plant

Model	Corollary Equipment		Feeding Size （mm）	Capacity (t/h)	Main Equipment Power (kw)
	Crushing Equipment	Screening Equipment
YCZ-V60	VSI8518	3YZS1848	＜40	100-130	198.5
YCZ-V85	VSI9526	3YZS1860	＜45	150-190	286
YCZ-CS-D70	CZS36D	3YZS1848	＜85	27-130	93.5
YCZ-CS-D120	CZS51D	3YZS1860	＜113	36-240	182
YCZ-HP-F100	HPC200F2	3YZS1860	＜75	90-190	182
YCZ-HP-F150	HPC300F2	3YZS2160	＜80	110-240	280
YCZ-HS-F80	HSC100F	3YZS1848	＜135	45-115	108.5
YCZ-HS-F125	HSC160F	3YZS1860	＜185	66-210	182

Note: 1. Any change of technical data will not inform additionally.
